The UniFi AC Pro AP supports simultaneous dual-band, 3x3 MIMO technology in the 5 and 2.4 GHz radio bands.
The UniFi Controller v4 software is a powerful, enterprise wireless software engine ideal for high-density client deployments requiring low latency and high uptime performance. With its software-based capabilities, the UniFi virtual control plane allows for unlimited scalability under one centralized controller. Remotely access the UniFi Controller to upgrade deployed UniFi APs while in the field.
| SPECIFICATIONS |
|
| Dimensions |
196.7 x 196.7 x 35 mm (7.74 x 7.74 x 1.38") |
| Weight |
350 g (12.4 oz), 450 g (15.9 oz) with Mounting Kits |
| Networking Interface |
(2) 10/100/1000 Ethernet Ports |
| Ports |
(1) USB 2.0 Port |
| Buttons |
Reset |
| Antennas |
(3) Dual-Band Antennas, 2.4 GHz: 3 dBi, 5 GHz: 6 dBi |
| Wi-Fi Standards |
802.11 a/b/g/n/ac |
| Power Method |
Passive Power over Ethernet (48V), 802.3af/803.2at Supported (Supported Voltage Range: 44 to 57VDC) |
| Power Supply |
Not Included |
| Maximum Power Consumption |
9W |
| Max TX Power |
22 dBm |
| BSSID |
Up to Four per Radio |
| Power Save |
Supported |
| Wireless Security |
WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES) |
| Certifications |
CE, FCC, IC |
| Mounting |
Wall/Ceiling (Kits Included) |
| Operating Temperature |
-10 to 70° C (14 to 158° F) |
| Operating Humidity |
5 to 95% Noncondensing |
| |
|
| ADVANCED TRAFFIC MANAGEMENT |
|
| VLAN |
802.1Q |
| Advanced QoS |
Per-User Rate Limiting |
| Guest Traffic Isolation |
Supported |
| WMM |
Voice, Video, Best Effort, and Background |
| Concurrent Clients |
200+ |
| |
|
| SUPPORTED DATA RATES (MBPS) |
|
| 802.11a |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11n |
6.5 Mbps to 450 Mbps (MCS0 - MCS23, HT 20/40) |
| 802.11ac |
6.5 Mbps to 1300 Mbps (MCS0 - MCS9 NSS1/2/3, VHT 20/40/80) |
| 802.11b |
1, 2, 5.5, 11 Mbps |
| 802.11g |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
